3.2V 7.5Ah Lithium-ion Rechargeable Cylindrical roj teeb
Jiangsu OptimumNano Energy Co., Ltd. (tom qab no hu ua "Jiangsu OptimumNano") yog lithium roj teeb lag luam platform raws li Tuam Tshoj Aerospace Science thiab Technology Group. Jiangsu OptimumNano yog lub hauv paus hauv Gaoyou City, Jiangsu Province, thiab nws lub hauv paus loj yog nyob rau hauv Gaoyou Economic Development Zone, nrog rau thaj tsam tag nrho ntawm 3,000 mu. Nws tau npaj kom ua tiav tag nrho cov peev txheej ntawm 50GWh los ntawm 2024, dhau los ua lub ntiaj teb loj tshaj plaws lithium hlau phosphate cylindrical qauv roj teeb tsim. Ntawm lawv, thawj theem ntawm txoj haujlwm muaj thaj tsam ntawm 137, 000 square metres, nrog 1 R&D pilot kab thiab 7 tag nrho cov cylindrical cell ntau lawm kab, nrog ib hnub tso zis ntawm 420, {{9} } loj cylindrical hlwb thiab muaj peev xwm tsim tau txhua xyoo ntawm 5GWh.
Jiangsu OptimumNano Customized Rechargeable Lifepo4 Lithium Ion Cell 3.2v 7.5Ah Hnub Ci Zog Cia Roj Teeb
Technical Parameters
Yam khoom | Qhov xwm txheej/Note | Specification | Tswv yim |
Nominal Peev Xwm | 0.5I1 tso zis muaj peev xwm | 7.5 aw | Standard them & tso tawm |
AC impedance | 10 feem pua SOC xeem ntawm 1000 Hz | Tsawg dua lossis sib npaug li 8.5mΩ | |
Nominal voltage | 3.2 V | ||
Loj | Cell Diameter | 32.2 ± 0.2 hli Max. 32.4mm ib | |
Cell Qhov siab | 8 ({2}}.5 ± 0.3 hli Max. 80.8mm ib | ||
Qhov hnyav | / | 162± 5 g | |
Qhov kawg ntawm tus nqi Voltage | CC hom | 3.65 V | |
Qhov kawg ntawm tus nqi tam sim no | CV Mode | 0.35A | |
Txoj Kev Them Nyiaj | Standard Charging | 0.5I1 ntawm CC/CV | |
Kev them nqi ceev ceev | 1 I1 at CC/CV | ||
Qhov kawg ntawm qhov tso tawm Voltage | DC hom | 2.75V (45 degree ~ 60 degree) 2.5V (20 degree ~ 45 degree) 2. 0 V (-20 degree ~ 20 degree) | |
Max nruam Discharge tam sim no | 15A | ||
Max Pulse Discharge Tam Sim No | 22.5 A | 5s | |
Lub neej voj voog | 1 I1 / 100% DOD | （20 degree ~ 30 degree）: Ntau dua lossis sib npaug rau 2000 cycles | |
Kev khiav hauj lwm qhov kub thiab txias | Kev them nyiaj kub | 0 ~ 60 degree | |
Tshem Tawm Kub | -20 ~ 60 degree | ||
Cia Kub | 1 xyoo | -10 ~ 40 degree | |
Qhov tshwm sim | Tsis muaj kev tawg, khawb, distortion, kis kab mob, xau thiab lwm yam | ||
Roj teeb nta
Cylindrical steel plhaub
Muaj peev xwm
Lub neej voj voog zoo heev
Kev ua tau zoo ntawm qhov kub thiab txias
Platform voltage ntev ntev '
Tsawg tus kheej tawm
Kev tiv thaiv ob npaug
Nrog zoo heev theem ntawm kev vibrations thiab shocks
Txog Peb
Raws li kev cai lij choj ntawm kev tsim kho kev lag luam thiab pab pawg txiav txim siab ntawm cov kev taw qhia ntawm kev tsim kho kev lag luam, Jiangsu OptimumNano rhuav tshem cov khoom lag luam ib txwm ua qauv thiab siv cov kev pabcuam uas sib koom ua ke "tus qauv khoom virtual ntau lawm kab qauv" thiab "cov neeg siv khoom siv tshuab customized khoom qauv", tsim ib lub roj teeb lithium tshwj xeeb. Ib theem tshiab thiab tshiab
FAQ
1. Peb tuaj yeem lav qhov zoo li cas?
Ib txwm ua qauv ua ntej ua ntej ua ntej ntau lawm
Ib txwm soj ntsuam zaum kawg ua ntej ua zaub mov xa tuaj
2.Koj tuaj yeem yuav dab tsi ntawm peb?
Roj teeb Cell, Roj Teeb Pob
3. Vim li cas koj yuav tsum yuav los ntawm peb tsis yog los ntawm lwm tus neeg muag khoom?
Cov kev paub dhau los thiab pab pawg tswj hwm txhua tus tuaj ntawm cov tuam txhab sab saum toj 3 hauv kev lag luam; Cov khoom siv dav siv hauv cov tsheb hluav taws xob qis qis, kev sib txuas lus hauv paus chaw nres tsheb, tsev cia khoom hluav taws xob thiab sab nraum zoov mini-emergency zog cia;
4. Peb tuaj yeem muab kev pabcuam dab tsi?
Txais Cov Lus Cog Tseg: null
Txais Nyiaj Them Nqi: USD
Hom Kev Them Nyiaj Txais: T / T
Lus Hais: Lus Askiv, Suav
